MS840-1 Multipoint systems

Multipoint systems

Specification

Material: Zinc alloy housing,handle, lock component,

carbon steel cam, timing chain

Surface: Mel Black powder coat housing, handle,

white zinc plated cam, timing chain

Structure description: Rotate the handle to open andclose the door

Default Key: K140

Notes:

Handle loading:≤ 400N

Handle torque: ≤35N.m

Maximum Static Load:270N(with cam)
