MS861-2(Old product) Swinghandle

Swinghandle

Specification:

Material: Zinc alloy handle, housing, carbon steel cam,

pressure plate;

Finish: White zinc plated cam and pressure plate;

Protection level: lP54;

Structure description: Rotates lock head component 90°,

the handle will open upward.

Rotate handle 90° to open and close the door,

Default key: K14

Notes :

Maximum handle torque: 12N.m

Maximum handle bearing tension: 390N

Maximum static load:300N
